E.3.2.2 Home > Administration > SNMP
Open the SNMP page from the Administration submenu. This page contains the following
options:
Hot
Key
Dialog Window Option Entry
A
Contact
Typical for each entry – Enter the desired designations
B
Name
C
Location
D Enable Authentication Traps Use the ↑↓ arrow keys to select Enabled or Disabled
E SNMP Trap Destination IP Address 1
Typical for either entry – Enter either IP Address in the form
XXX.XXX.XXX.XXX
F SNMP Trap Destination IP Address 2
G SNMP Trap Version Use the ↑↓ arrow keys to select SNMP V1 or SNMP V2
H SNMP Trap Community
Enter the desired Trap Community name – the default name is
comtech
Press a hot key to open a dialog window. Otherwise, press [ESC] to return to the Administration
submenu.
