CDM-625 Advanced Satellite Modem Revision 13
Front Panel Operation MN-CDM625
5–76
5.2.3.8 Monitor: IP Statistics
IPstats: Port x In Out ()
Unicasts: 00000003 00000023 Clr:N
This screen is identical to and displays the same performance information as the screen shown
in Sect. 5.2.1.13.3
CONFIG: IP  Setup  Stats.
5.2.4 SELECT: Info (Information) Menus
Info: All ID Mode Tx Rx Clocks EDMAC
Drop Insert Remote Alarm-Mask Misc
The read-only INFO screens display the modem’s current configuration information without
risking inadvertent changes.
Use the
◄ ►arrow keys to select All, ID, Mode, Tx, Rx, Clocks, EDMAC, Drop, Insert, Remote,
Alarm-Mask, or Misc, and then press ENTER.
After viewing any Info screen except All: Press ENTER or CLEAR to return to the previous menu.
5.2.4.1 Info: All
All = Start
(Stop, Start) ()
Use this menu to scroll through and review configuration settings on a sequential basis. The
configuration displays are read-only – no editing is possible.
To view the configurations – Use the
▲▼ arrow keys to select between Stop and Start. Press
ENTER to continue through all the displays.
To discontinue viewing – Press CLEAR, use the
▲▼ arrow keys to select Stop, and then press
ENTER.
5.2.4.2 Info: ID
Modem Circuit ID:
----A TEST MESSAGE TO SHOW CIRCUIT ID---
This screen displays the 40-character, user-defined Circuit ID string that was created using the
Utility
Circuit-ID menu. The Circuit ID also appears in the title bar of compatible web browsers
for easy unit identification.
