CDM-625 Advanced Satellite Modem Revision 13
Appendix F MN-CDM625
F–21
F.3.3.3.3.2 ODU: FSK-control  2CSATs
The menus that follow assume that you have selected and the system has identified
two CSATs connected via the Rx IF port and the ODU Redundancy Controller Box.
1:1 Monitor & Control
CSAT#1 CSAT#2 Redundancy-Box ()
Use the
◄ ►arrow keys to select CSAT#1, CSAT#2, or Redundancy-Box, and then press ENTER.
F.3.3.3.3.2.1 ODU: FSK-control  2CSATs  CSAT#X
This submenu and its nested menus are identical in form and function for the
following menu structures:
ODU: FSK-control

CSAT

ODU: FSK-control

2CSATs

CSAT#X

(where CSAT#X = CSAT#1, CSAT#2)
CSAT-5060/050 V1.02
Configuration Monitor Alarms Info ()
Use the
◄ ►arrow keys to select Configuration, Monitor, Alarms, or Info, and then press
ENTER.
Sect. F.3.3.3.3.1 ODU: FSK-control

CSAT for complete information for these
nested menu choices.
F.3.3.3.3.2.2 ODU: FSK-control  2CSATs  Redundancy-Box
Red: Online: ODU2 Mode:Auto Switch:N
TxSw:OK RxSw:OK 5V:5.0 12V:12.0
This menu provides operating mode and switchover controls. You may also view the following
read-only information here:
• Which of the two CSATs in currently online (ODU1 or ODU2);
• Waveguide Switch Tx and Rx status: OK or Ft (fault);
• Redundancy Controller Box 5V and 12V values (to aid trouble-shooting system
problems).
