CDM-625 Advanced Satellite Modem Revision 13
Appendix F MN-CDM625
F–22
To set Operating Mode, use the ◄ ►arrow keys to select Mode, and then use the ▲▼ arrow
keys to select this mode as Auto or Manual:
• AUTO mode – When the Online ODU faults, the switchover is done automatically to
replace the faulty unit.
If the ODU Redundancy system is in AUTO mode, a ‘forced switch-over’ can
only occur if the currently OFFLINE unit is fault-free.
• MANUAL mode – If selecting the mode as Manual, there is no automatic switchover if a
fault occurs.
To force a switchover to the other CSAT unit, use the
◄ ►arrow keys to select Switch: N, and
then use the
▲▼ arrow keys to select Y (Yes). Press ENTER when done.
