CDM-625 Advanced Satellite Modem Revision 13
Front Panel Operation MN-CDM625
5–82
5.2.6.4 Utilities: LED
Front Panel LED Test: Enabled
(Enable,Disable) ()
Use the
▲▼ arrow keys to select Enable or Disable, and then press ENTER to continue. When
enabled, a test of all of the LEDs on the front panel is executed. Normal operations resume upon
completion of the test.
5.2.6.5 Utilities: Redundancy
Redundancy:
Traffic-IP-Addr/Range 1:1 1:N
Use the
▲▼ arrow keys to select Traffic-IP-Addr/Range, 1:1, or 1:N, and then press ENTER.
5.2.6.5.1 Utilities: Redundancy Traffic-IP-Addr/Range
Traffic IP address/Range
192.168.001.001/24 ()
To edit the Traffic IP Address and range, when the modem is part of a 1:1 or 1:N redundancy
application: First, use the
◄ ►arrow keys to select a digit to edit, and then use the ▲▼ arrow
keys to change that digit. Press ENTER when done.
5.2.6.5.2 Utilities: Redundancy 1:1
Press ENTER key to force Unit into
Standby (1:1 only)
For use when the modem is part of a 1:1 redundancy application (e.g., via a CRS-170A L-Band or
CRS-180 70/140 MHz 1:1 Redundancy Switch) and this unit is currently Online, press ENTER to
cause the unit to switch to Standby (i.e., go Offline).
5.2.6.5.3 Utilities: Redundancy 1:N
1:N Mode: (use with CAUTION!)
Disabled (Enable, Disable) ()
For use when the unit is part of a 1:N redundant application (e.g., via a CRS-300 1:10
Redundancy Switch). Use the
▲▼ arrow keys to select 1:N Mode operation as Enable or
Disable, and then press ENTER.
