CDM-625 Advanced Satellite Modem Revision 13
Appendix E MN-CDM625
E–28
E.3.3.4 Home > Modem > Carrier-in-Carrier (CnC)
Chapter 10. DOUBLETALK CARRIER-IN-CARRIER (CNC) OPTION
Open the Carrier-in-Carrier (CnC) page from the Modem submenu. This page contains the
following options:
Hot
Key
Dialog Window Option Entry
A CnC Mode
Use the ↑↓ arrow keys to select:
• Off • On Normal • APC CBand Side A
• APC XBand Side A • APC KuBand Side A • APC KaBand Side A
• APC CBand Side B • APC XBand Side B • APC KuBand Side B
• APC KaBand Side B
B
CnC Search Min Delay
Enter a minimum value from 0 to 330 ms
C CnC Search Max Delay Enter a maximum value from 0 to 330 ms
D
CnC Frequency Offset
Enter a value from 1 to 200 KHz
E CnC PMSI Mode Use the ↑↓ arrow keys to select Idle, Redundancy, Talk, or Listen
Press a hot key to open a dialog window. Otherwise, press [ESC] to return to the Modem
submenu.
