CDM-625 Advanced Satellite Modem Revision 13
Front Panel Operation MN-CDM625
5–53
All printable ASCII characters are available with the exception of the backslash (ASCII code 92)
and ~ (ASCII code 126).
Press ENTER after composing the SNMP Traps Community String. All trailing spaces are removed
from the string upon entry.
CONFIG: IP  SNMP  Traps  Version
SNMP Traps Version:
SNMP-ver1 (ver1,ver2) ()
Use the
◄ ►arrow keys to select SNMP-ver1 or SNMP-ver2, and then press ENTER.
CONFIG: IP  SNMP  Traps  Address
Trap IP addr #1:
000.000.000.000 ()
To edit the SNMP Trap Destination’s IP Address, use the
◄ ►arrow keys to select a digit to edit,
and then use the
▲▼ arrow keys to change that digit.
To disable SNMP Traps, set both Trap IP Addresses as 000.000.000.000.
5.2.1.13.3 CONFIG: IP  Setup
IP Setup: Mode WAN PerPortCnfg DDMgmtPt
MAC-Learning VLAN QoS Stats FrmSize ()
Use the
◄ ►arrow keys to select Mode, WAN, PerPortCnfg, DDMgmtPt, MAC-Learning, VLAN,
QoS, Stats, or – displayed only on modems with Hardware Version 2.X or higher – FrmSize, and
then press ENTER.
If the optional IP Packet Processor card is installed and enabled, then both the PTP
and VLAN options are selectable but non-functional.
CONFIG: IP  IP Setup  Mode
Working Mode: Router Point to Point
(ManagedSwitch,R-PtoP, R-MPHub,R-MPRm)()
Use the
◄ ►arrow keys to select ManagedSwitch, R-PtoP (Router Point-to-Point), R-MPHub
(Router Multipoint-to-Hub), or R-MPRm (Router Multipoint-to-Remote), and then press ENTER.
