CDM-625 Advanced Satellite Modem Revision 13
Introduction MN-CDM625
1–4
1.3.3 Ethernet/IP Interface Compatibility
HDLC Encapsulation
CDM-625 Configuration
Compatible
CEFD IP Modem
Compatible CEFD
IP Modem
Firmware
Compatible CEFD IP Modem
Configuration
Standard 4-port Ethernet Data
Interface without optional IP
Packet Processor – Managed
Switch Mode*
CDM-570/570L
with IP Module
CDM-570/570L IP
Firmware Versions
1.5.4 to 1.6.X
CDM-570/570L must have Layer
2 (L2) Tx and Rx Header
Compression disabled –
Managed Switch Mode*
Standard 4-port Ethernet Data
Interface without optional IP
Packet Processor – Managed
Switch Mode*
CDD-562L/564
IP Demodulator
CDD-562L/564 IP
Firmware Versions
1.5.4 to 1.6.X
CDD-562L/564 must have Layer
2 (L2) Tx and Rx Header
Compression disabled –
Managed Switch Mode*
Streamline Encapsulation
CDM-625 Configuration
Compatible
CEFD IP Modem
Compatible CEFD IP
Modem Firmware
Compatible CEFD IP
Modem Configuration
Optional IP Packet Processor –
Managed Switch Mode*
CDM-570/570L
with IP Module
CDM-570/570L IP
Firmware Version 1.7.0 or
later
Managed Switch Mode*
Optional IP Packet Processor –
Managed Switch Mode*
CDD-562L/564
IP Demodulator
CDD-562L/564 IP Firmware
Version 1.7.0 or later
Managed Switch Mode*
Optional IP Packet Processor –
Router Mode
CDM-570/570L
with IP Module
CDM-570/570L IP
Firmware Version 1.7.0 or
later
Router Mode
Optional IP Packet Processor –
Router Mode
CDD-562L/564
IP Demodulator
CDD-562L/564 IP Firmware
Version 1.7.0 or later
Router Mode
*Note: Managed Switch Mode is also known as Ethernet Bridge Mode.
1.3.4 Verification
The CDM-625 includes many test modes and loopbacks for rapid verification of the correct
functioning of the unit. Of particular note is the IF loopback, which permits you to perform a
quick diagnostic test without having to disturb external cabling. During the loopback, all of the
receive configuration parameters are temporarily changed to match those of the transmit side,
and an internal RF switch connects the modulator output to the demodulator input. When
normal operation is again selected, all of the previous values are restored.
1.3.5 Updating Modem Firmware
Chapter 4. UPDATING FIRMWARE
The CDM-625 stores its firmware internally in flash memory, which simplifies the firmware
updating process without having to open the modem. Firmware downloads are available via the
