E.3.10 Home > Statistics Submenu
The Telnet CLI Statistics submenu provides access to a number of read-only informational pages.
Most page submenus provide a dialog window that affords you the option to reset (clear) the
counters for that specific page.
Open the Statistics submenu from the Home menu:
Hot
Key
Page Description Sect.
A Ethernet
Access pages to review Ethernet Ports 1 through 4 Rx, Tx,
and Error Statistics
E.3.10.1
B
Router Review received, routed, transmitted, and errored packets
E.3.10.2
C Managed Switch
Review Managed Switch LAN/WAN/Management received,
transmitted, and errored packets statistics
E.3.10.3
D WAN (Router Mode)
Review Router Mode WAN/Interface/Satellite received,
transmitted, and errored packets and counters statistics
E.3.10.4
E WAN (Managed Switch Mode)
Review Managed Switch Mode WAN/Interface/Satellite
received, transmitted, and errored packets and counters
statistics
E.3.10.5
F Compression Review payload and header compression statistics E.3.10.6
G QoS Review Quality of Service statistics E.3.10.7
H PTP Access pages to review LAN/WAN/PTP Engine statistics E.3.10.8
I CPU Review CPU total, kernel and apps usage statistics E.3.10.9
J Reset Counters Clear and reset all counters E.3.10.10
Press a hot key to access a nested statistics page submenu. See the specified appendix section
for further information. Otherwise, press [ESC] to return to the Home menu.
