CDM-625 Advanced Satellite Modem Revision 13
Ethernet-based Remote Product Management MN-CDM625
6–29
• VLAN Table – This read-only table provides the user with the status for VLAN entry on a per-
ID (0001-4095) and per-Port (1-4) basis, where U=Untagged, T=Tagged, and F=Filtered.
6.5.4.3.2.2 Configuration | LAN | ARP
This nested
page is accessible only to Admin users and when the optional IP Packet
Processor card is installed and enabled. See Sect. 6.5.3.1 for complete details about
using conditional access pages.
ARP (Address Resolution Protocol) is a technique by which the Web Server Interface in Router
Mode on a given network answers the ARP queries for a network address that is not on this
network, but is reachable via the IP Packet Processor Interface.
Use this page to configure the modem’s ARP parameters.
Figure 6-15. Configuration | LAN | ARP page
ARP Table (Edit)
This section displays all current Static and Dynamic ARP entries, and allows to user to directly
edit the current Static ARP entries, when more than one ARP entry exists. Note the following:
Column
Description
Index
This is the internal table index that is automatically assigned and cannot be edited.
IP
IP Address, in the format XXX.XXX.XXX.XXX.
MAC
MAC Address, in the format YY:YY:YY:YY:YY:YY.
Type
Type is identifiable as Static or Dynamic (cannot be edited).
Click [Submit Changes] to save these settings.
