6–1
Chapter 6. ETHERNET-BASED
REMOTE PRODUCT
MANAGEMENT
6.1 Introduction
The CDM-625 Advanced Satellite Modem base unit is equipped with four RJ-45 10/100 BaseT
Ethernet connectors, subject to the following conditions:
• When Dedicated Management is disabled, you may use any port for Ethernet-based
remote product management (monitor and control) purposes.
• When Dedicated Management is enabled, you may use only that specific port for remote
monitor and control (M&C) purposes.
6.2 Ethernet Management Interface Protocols
The user PC facilitates access to Ethernet-based remote M&C of the CDM-625 through three
separately-operated protocols:
• Simple Network Management Protocol (SNMP) – This requires a user-supplied Network
Management System (NMS) and a user-supplied Management Information Base (MIB) File
Browser.
• Telnet Interface – This requires use of a user-supplied terminal emulation program such as
HyperTerminal (for use with the remote control protocol) or PuTTY (for use with the Telnet
Command Line Interface), installed on the user PC.
• CDM-625 Web Server (HTTP) Interface – This requires a compatible user-supplied web
browser such as Internet Explorer, installed on the user PC.
