CDM-625 Advanced Satellite Modem Revision 13

Appendix E MN-CDM625

E–81

E.3.10.3 Home > Statistics > Managed Switch

Open the Managed Switch statistics page from the Statistics submenu:

Hot

Key

Dialog Window Option Entry

Router Clear Stats

Use the ↑↓ arrow keys to select Cancel or Clear

Press the hot key to open the dialog window. Otherwise, press [ESC] to return to the Statistics

submenu.
