Follow these steps to install the optional KT/6228 (4”) or KT/6228 (10”) Rear-Mounting Support
Brackets Kit:
Step
Task
1
Use the #10 flat washers, #10 split washers, and #10 hex nut to secure the #10 shoulder screws to the unit
chassis through the rear right and left side mounting slots as shown.
2
Use the #10 rack bracket bolts to install the rear support brackets onto the rack enclosure threaded rear
mounting rails.
3
Mount the unit into the rack enclosure. Ensure that the shoulders of the #10 shoulder screws properly engage
into the rear support bracket slots.
2.3 Configuring the CDM-625
Chapter 5. FRONT PANEL OPERATION
The unit is shipped with a default 64 kbps, QPSK, Rate 1/2 configuration. There are no internal
jumpers to configure, no interface cards to install, and no other options to install. All
configurations are carried out entirely via the modem’s installed firmware – use the front panel
keypad and display to configure the modem locally.
The auto-sensing AC power supply does not require any adjustments. Simply plug
in the supplied line cord, and turn on the rear panel switch.
2.4 Selecting the Internal IF Loop
Chapter 5. FRONT PANEL OPERATION – Sect. 5.2.2 SELECT: Test Menus
You may quickly verify proper operation of the modem without the need for externally
connected equipment. From the top level menu, select TEST: Mode →
IF↓ (IF LOOP).The demod
should synchronize, and the Rx TRAFFIC LED should illuminate GREEN. If the unit does not pass
this test, call Comtech EF Data’s Customer Support department for assistance.
2.5 Connecting the External Cables
Chapter 3. REAR PANEL CONNECTORS AND PINOUTS
Having verified correct operation via the Internal IF loop test, enter the desired configuration
and then connect all external cables. If difficulties occur, call Comtech EF Data’s Customer
Support department for assistance.
