CDM-625 Advanced Satellite Modem Revision 13

Ethernet-based Remote Product Management MN-CDM625

6–68

6.5.4.4.4.4 Status | Traffic Statistics | WAN

This p age a ppearance is d ependent o n w hether th e o ptional I P Packet

Processor c ard i s not installed / installed but disabled or if it is installed and

enabled

. See S ect. 6.5.3.1 for complete details about using conditional a ccess

pages.

Use this page to view cumulative WAN traffic information.

Figure 6-40. Status | Traffic Statistics | WAN page

(Top) Page when optional IP Packet Processor is either not installed or installed but disabled

(Bottom) Page when optional IP Packet Processor is installed and enabled
