Comtech EF Data CDM-625 - Figure F-4. CDM-625 Web Server (HTTP) Interface Menu Tree (FW Ver. 2.3.1)

To Next Page

To Previous Page

CDM-625 Advanced Satellite Modem Revision 13

Appendix F MN-CDM625

F–37

(shown in blue). Beyond this top-level row of navigation tabs, the diagram illustrates the available

primary (green) and nested (yellow) page tabs that afford you more specific functionality.

Tabs not specific to ODU operation appear dimmed and are explicitly defined in Chapter 6.

ETHERNET-BASED REMOTE PRODUCT MANAGEMENT. Click a navigation tab to continue.

Pages marked with double asterisks (**) are operable only when BUCs or LNBs

are installed.

Figure F-4. CDM-625 Web Server (HTTP) Interface Menu Tree (FW Ver. 2.3.1)
