CDM-625 Advanced Satellite Modem Revision 13
Front Panel Operation MN-CDM625
5–85
done – a message will then prompt you to reboot the unit in order for the newly-selected image
to be loaded upon startup.
5.2.6.7.2 Utilities: Firmware Packet-Processor
Packet Processor Firmware Information:
Boot-ROM Image#1* Image#2 Select ()
This screen identifies the optional CDM-625 IP Packet Processor internal firmware image that is
loaded on startup or reboot of the Base Modem with an asterisk (*).
Use the
◄ ►arrow keys to select Boot-Rom, Image#1, Image#2, or Select, and then press
ENTER.
5.2.6.7.2.1 Utilities: Firmware Packet-Processor Boot-ROM,
Image#X
Bootrom: DD/MM/YY HH:MM:SS
FW-0000346X #.#.#
The example shown here is for the IP Packet Processor Bootrom firmware opening screen.
Typical for the Bootrom, Image#1 or Image#2 screens, read-only information is provided for:
firmware type; its number (where ‘X’ is the revision letter); its build date- and time-stamps (in
day/month/year and hours/minutes/seconds formats); and its version number (e.g., 1.3.3).
Press ENTER or CLEAR to return to the previous menu.
5.2.6.7.2.2 Utilities: Firmware Packet-Processor Select
Current Active Image is #1
Next Reboot, will use Image: #2 ()
The modem can store two complete firmware images, and you can select which image loads the
next time the unit reboots. The top line shows the current active image while, on the bottom
line, you may use the
▲▼ arrow keys to select the other image. Press ENTER when done – a
message will then prompt you to reboot the unit in order for the newly-selected image to load
upon startup.
