F.5.1.2.1.5 Home > Outdoor Unit (ODU) > CSAT-5060 > Status

Open the read-only Status page from the nested CSAT-5060 submenu. This page provides the

following information:

Item Description

Online State Identifies the unit as Online or Offline

Maintenance Parameters Info needed

Unit Faults

Lists the curren t number of unit faults

Number Unread Events

Lists the number of unread events that are currently stored in the Events

Log

Press [ESC] to return to the nested CSAT-5060 submenu.
