A-1
Appendix A. CABLE DRAWINGS
A.1 Overview
The EIA-530 standard pinout, provided on the CDM-625, is becoming more popular in many applications. However, there are still many
occasions – especially for existing EIA-422/449 and V.35 users – when a conversion is required. For these situations:
• Figure A-1 depicts the cable required for EIA-530 -to- EIA-422/449 DCE conversion.
• Figure A-2 depicts the cable required for EIA-530 -to- V.35 DCE conversion.
• Figure A-3 depicts a standard EIA-232 cable for connection between the CDM-625 Rear Panel Remote Control port and any
serial port on the user PC.
