Comtech EF Data CDM-625 - Figure 6-39. Status | Traffic Statistics | Managed Switch Page; Status | Traffic Statistics

To Next Page

To Previous Page

CDM-625 Advanced Satellite Modem Revision 13

Ethernet-based Remote Product Management MN-CDM625

6–67

6.5.4.4.4.3 Status | Traffic Statistics | Managed Switch

This n ested p age i s accessible o nly to Admin u sers a nd w hen the optional IP

Packet Processor ca rd is installed and enabled. See Sect. 6.5.3.1 for complete

details about using conditional access pages.

Use this page to view cumulative Managed Switch traffic information.

Figure 6-39. Status | Traffic Statistics | Managed Switch page

Clear Statistics

Click [Clear] to clear all Managed Switch statistics from the buffer.

Click [Refresh] to update the page with the latest available statistics.
