CDM-625 Advanced Satellite Modem Revision 13

Appendix E MN-CDM625

E–36

E.3.3.10 Home > Modem > Utilities

Open the scrollable Utilities page from the Modem submenu. This page contains the following

options:

Hot

Key

Dialog Window Option Entry

Unit Test Mode

Use the ↑↓ arrow keys to select

•

Normal

•

Tx CW

•

Tx Alt10 Pattern

•

IF Loopback

•

RF Loopback

•

Digital Loopback

•

I/O Loopback
