CDM-625 Advanced Satellite Modem Revision 13
Appendix F MN-CDM625
F–27
F.3.3.3.3.4.3.1 ODU: FSK-control  BUC  Advanced-FSK  LPOD
(2LPODs
 Online/Offline LPOD)
LPOD S/N: 123456789
Cnfg Monitor Alarms Stats Info Redun ()
This submenu and its nested menus are identical in form and function for the
following menu structures:
ODU: FSK-control

Advanced-FSK

LPOD

ODU: FSK-control

Advanced-FSK

2LPODs

Online LPOD

ODU: FSK-control

Advanced-FSK

2LPODs

Offline LPOD

Use the
◄ ►arrow keys to select Cnfg, Monitor, Alarms, Stats, Info, or Redun, and then press
ENTER.
F.3.3.3.3.4.3.1.1 ODU: FSK-control  BUC  Advanced-FSK  LPOD
(2LPODs
 Online/Offline LPOD)  Cnfg
Configuration settings:
Amplifier LNB Mask Misc ()
Use the
◄ ►arrow keys to select Amplifier, LNB, Mask, or Misc, and then press ENTER.
ODU: FSK-control  BUC  Advanced-FSK  LPOD (2LPODs 
Online/Offline LPOD)
 Cnfg  Amplifier
Amplifier: Att=10.00 dB Amp=On
Mute=Disabled Att-Offset=00.00 dB ()
Use the
◄ ►arrow keys to select the setting to edit, and then use the ▲▼ arrow keys to edit
that setting:
Selection
Setting
Att
(Attenuation) 0 to 20 dB, in increments of .25dB. Limit and increments are variable
based upon unit Info string.
Amp (Amplifier setting) Off or On
Mute
(Mute Mode) Disabled
(i.e., Tx off) or
Enabled
(i.e., Tx on)
Att-Offset
(Attenuation Offset)
0 to 20 dB, in .25 dB increments
Press ENTER when done.
