E.3.4.10 Home > Network > PTP (Precision Time Protocol)

Open the PTP (Precision Time Protocol) page from the Network submenu. This page contains the

following options:

Hot

Key

Dialog Window Option Entry

PTP Feature

Use the ↑↓ arrow keys to select Disable or Enable

PTP Grandmaster

Use the ↑↓ arrow keys to select LAN or WAN

Press a hot key to open a dialog window. Otherwise, press [ESC] to return to the Network

submenu.
