F.3.3.3.3.3 ODU: FSK-control  KST
KST Select:
Configuration Information Alarms ()
Use the
◄ ►arrow keys to select Configuration, Information, or Alarms, and then press ENTER.
F.3.3.3.3.3.1 ODU: FSK-control  KST  Configuration
KST Config:
Tx Rx Miscellaneous ()
Use the
◄ ►arrow keys to select Tx, Rx, or Miscellaneous, and then press ENTER.
F.3.3.3.3.3.1.1 ODU: FSK-control  KST  Configuration  Tx
Tx:Off Freq=13955 MHz Att=23 dB
AGC=Off ()
Use the
◄ ►arrow keys to select Tx, Freq, Att, or AGC, and then use the ▲▼ arrow keys to edit
that setting. Press ENTER when done.
F.3.3.3.3.3.1.2 ODU: FSK-control  KST  Configuration  Rx
Rx: Freq=11950 MHz Att=20 dB Ref=087
Band=B ()
Note that Rx Band is not shown for the KST-2000A.
Use the
◄ ►arrow keys to select Freq, Att, Ref, or Band (KST-2000B only), and then use the
▲▼ arrow keys to edit that setting. Press ENTER when done.
F.3.3.3.3.3.1.3 ODU: FSK-control  KST  Configuration 
Miscellaneous
HPA:Off Fault-Logic=Summary
LNA:OFF Fault-Logic=Summary Cal:No
Use the
◄ ►arrow keys to select HPA, (HPA) Fault-Logic-Summary, LNA, (LNA) Fault-Logic-
Summary, or Cal, and then use the
▲▼ arrow keys to edit that setting:
Selection Setting
HPA (HPA power enable) Select Off or On.
