CDM-625 Advanced Satellite Modem Revision 13
Appendix F MN-CDM625
F–24
Selection Setting
Fault-Logic
This controls whether or not a HPA fault is indicated on t he Fault status, and ac tivates
the Summary Fault Relay. Select Summary or No-Summary.
LNA (LNA power enable) Select Off or On.
Fault-Logic
This controls whether or not a L NA fault is indicated on the Fault status, and l activates
the Summary Fault Relay. Select Summary or No-Summary.
Cal
To c alibrate, select
and press
. Calibration allows the system to determine
nominal LNB or LNB power consumption, performed at initial installation only. (Default is
NO.)
Press ENTER when done.
F.3.3.3.3.3.1.4 ODU: FSK-control KST Information
KST Info: Model Tx+Rx-Param
Misc Numbers ()
These read-only screens provide the ODU’s current configuration information without risking
inadvertent changes.
Use the
◄ ►arrow keys to select Model, Tx+Rx-Param, Misc, or Numbers, and then press
ENTER.
Once any KST Info screen has been viewed, press ENTER or CLEAR to return to the previous
menu.
F.3.3.3.3.3.1.5 ODU: FSK-control KST Information Model
MODEL: KST-2000B
HPA: CEFD-SSPA
This screen displays the KST and HPA model numbers.
F.3.3.3.3.3.1.6 ODU: FSK-control KST Information Tx+Rx-Param
Info: Tx:Off 13955MHz 10dB
Rx: 11950MHz 20dB Ref:087
This screen displays the Tx and Rx states, Frequencies, and Attenuation, and the reference.
