CDM-625 Advanced Satellite Modem Revision 13
Appendix F MN-CDM625
F–25
F.3.3.3.3.3.1.7 ODU: FSK-control KST Information Misc
Info: HPA:Off Flt-Logic:No-Summ
Band:B LNA:Off FLT-Logic:Summary
This screen displays the HPA and LNA operational and fault logic summary settings.
Note that the Rx Band information is not shown for the KST-2000A.
F.3.3.3.3.3.1.8 ODU: FSK-control KST Information Numbers
M&C: F/W:9364-1B VER:01.01.03
assy:9357-1A S/N:021476493
Use the
▲▼ arrow keys to view the Up-Converter, Down-Converter and HPA assembly and
serial numbers as well as their firmware numbers/versions.
F.3.3.3.3.3.1.9 ODU: FSK-control KST Alarms
Current Status: Up:OK Ref:OK AGC:OK
P-Supplies:OK Dn:OK HPA:OK LNA:OK
This is Summary Status information. Use the
◄ ►arrow keys to select Up, Ref, AGC, Power-
Supplies, Down, HPA, or LNA, and then press ENTER. A detailed status screen, similar to the
following examples, is then shown:
Up-Converter: Comms:OK L-Synth:OK
Over-Temp:OK Ku-Synth:OK
Reference:Warm 72M-Lock:OK Range:NA
Source:IntT Xref-Lock:NA Phase:NA
AGC Status: Excess-Power-In:OK
Loop-Conv:OK Insuff-Power-In:OK
P-Supplies: 7V:OK 17V:OK
-7V:OK 12V:OK (EC)
Down-Converter: Comms:OK L-Synth:OK
Over-Temp:OK Ku-Synth:OK
