Comtech EF Data CDM-625 - Miscellaneous; 1.4.10 Approvals

CDM-625 Advanced Satellite Modem Revision 13
Introduction MN-CDM625
1–30
1.4.9 Miscellaneous
Front Panel
Tactile keypad, 6 keys (Up/Down), Left/Right, Enter/Clear)
Vacuum Fluorescent Display (blue) – 2 lines of 40 characters
Loopbacks
Internal IF loopback, RF loopback, digital loopback, and inward/outward loopback
Fault relays
Hardware fault, Rx and Tx Traffic Alarms, Open Network Backward Alarms
Type: Form C Contacts. Rating: Up to +/-50 volts, max 0.5 Amp
M&C Interface EIA-232 and EIA-485 (addressable multidrop, 2-wire or 4-wire) or Ethernet (10/100 BaseT)
M&C Software Serial comms, SNMP, Telnet, Web Server (HTTP)
Firmware update Via Ethernet port. ftp protocol
Dimensions 1RU high, 17.65 inches (448 mm) deep
Weight
10.5 lbs (4.8 kg) max (All option cards and 48V BUC supply installed)
AC consumption 48 watts (typical, TPC/LDPC Codec and CnC module installed), 68watts (maximum)
280 watts (typical TPC/LDPC Codec, CnC module and 48 volt BUC supply installed, 300 watts (max)
AC operating voltage 100 - 240 VAC Nominal - autosensing
90 – 264 VAC Maximum
DC consumption (option)
As above (AC consumption)
DC operating voltage
43-60 VDC Nominal
36 – 60 VDC Maximum
Operating temperature
0 to 50ºC (32 to 122ºF)
1.4.10 Approvals
“CE” as follows: EN 55022 Class B
(Emissions)
EN 50082-1 (Immunity)
EN 60950-1 (Safety)
EN 61000-3-2
EN 61000-3-3
EN 61000-4-2
EN 61000-4-4
EN 61000-4-5
EN 61000-4-6
EN 61000-4-8
EN 61000-4-9
EN 61000-4-11
EN 61000-4-13
FCC
Federal Communications Commission Federal Code of Regulation FCC Part 15, Subpart B.
