CDM-625 Advanced Satellite Modem Revision 13

Appendix F MN-CDM625

F–61

F.5.1.2.1.4 Home > Outdoor Unit (ODU) > CSAT-5060 > LNA Settings

Open the LNA Settings page from the nested CSAT-5060 submenu. This page contains the

following options:

Hot

Key

Dialog Window Option Entry

A Unit LNA Current Window

Enter a value as follows:

• Range 1 – 20 to 50

•

Range 2 – 99 to 99

B Unit LNA Current Window

Use the ↑↓ arrow keys to select Disabled, Enabled, or Enabled

When Online

Unit LNA Fault Logic

Use the ↑↓ arrow keys to select No Summary or Summary

Press a hot key to open a dialog window. Otherwise, press [ESC] to return to the nested CSAT-

5060 submenu.
