CDM-625 Advanced Satellite Modem Revision 13

IP Packet Processor Option MN-CDM625

18–10

18.5.3 Field Upgrade Procedure

Step

Task

Turn off the CDM-625 and disconnect the modem’s power

cord from its power source.

Next, use the screwdriver to remove the top cover mounting

hardware. Remove the cover from the CDM-625 chassis.

IMPORTANT: Be s ure t o r etain the top cover mounting

hardware for cover re-installation once you have installed

the IP Packet Processor Card and its cooling fan.
