CDM-625 Advanced Satellite Modem Revision 13
Ethernet-based Remote Product Management MN-CDM625
6–71
6.5.4.4.4.7 Status | Traffic Statistics | PTP
Sect. 16.7.2 Precision Time Protocol (PTP) (Chapter 16. ETHERNET NETWORK
MANAGEMENT)
Use this page to obtain data intended to troubleshoot PTP operational issues.
Figure 6-43. Status | Traffic Statistics | PTP page
PTP Status
Click [Refresh] to update this section with its most recently accumulated statistics.
These status parameters are read-only and cannot be changed. Note the following:
Row
Title
Description
Top
PTP Engine
Specifies whether or not PTP is actively attempting to synchronize time.
PTP Time
Displays the time that has been synchronized with the master device and is being
propagated to the slave devices.
Bottom
PTP Port
Displays whether or not the Ethernet link is detected. The PTP Port is always
Ethernet Port 2 on the modem.
RTV Time
Displays the presumed time for the modem. While the PTP time depends on the
Grandmaster device, the RTC Time changes only when set by the user.
