F.5.1.2.1 Home > Outdoor Unit (ODU) > CSAT-5060 Submenu
Open the nested CSAT-5060 submenu from the Outdoor Unit (ODU) submenu. This submenu
contains the following options:
Hot
Key
Dialog Window Option Entry Sect.
A Select Use the ↑↓ arrow keys to select Csat1 or Csat2 N/A
B Up Converter Settings (1/2)
Configure an Up Converter F.5.1.2.1.1
C Up Converter Settings (2/2)
D Down Converter Settings (1/2)
Configure a Down Converter F.5.1.2.1.2
E Down Converter Settings (2/2)
F Unit Settings (1/2)
Configure an ODU F.5.1.2.1.3
G Unit Settings (2/2)
H
LNA Settings
Configure a Low Noise Amplifier
F.5.1.2.1.4
I
Status
Review ODU Status Information
F.5.1.2.1.5
J
Logs
Review and manage Event Logs
F.5.1.2.1.6
K
Redundancy
Configure ODUs for 1:N Redundancy
F.5.1.2.1.7
L Utilities
Set device time and date, review the unit’s firmware
version and serial number
F.5.1.2.1.8
Press a hot key to open a dialog window or configuration page. See the specified appendix
section for further configuration options. Otherwise, press [ESC] to return to the ODU submenu.
