CDM-625 Advanced Satellite Modem Revision 13

Forward Error Correction Options MN-CDM625

7–24

Figure 7-11. Rate 21/44 BPSK, QPSK, OQPSK Turbo Product Codec

1E-9

1E-8

1E-7

1E-6

1E-5

1E-4

1E-3

1E-2

1E-1

1 2 3 4 5 6 7 8 9 10 11 12

Eb/No in dB

Uncoded

BPSK/QPSK

Comtech Turbo Product Codec

Rate 21/44 BPSK/QPSK/OQPSK

1 2 3 4 5 6 7 8 9 10 11 12

BER

Spec limit

Rate 21/44

B/Q/OQPSK

Typical performance

* Rate 21/44 QPSK is

shown as R1/2 on the

front panel

* The OQPSK acquisition

and tracking thresholds

are approx. 1 dB worse

than the QPSK case

Notes:
