CDM-625 Advanced Satellite Modem Revision 13
Front Panel Operation MN-CDM625
5–51
CONFIG: IP  Addresses  MAC
Ethernet MAC Address:
00-06-B0-00-01-06 (read-only)
This read-only screen displays the unit MAC address. Press ENTER or CLEAR to return to the
previous menu.
CONFIG: IP  Addresses  Gateway
Ethernet IP Gateway:
192.168.001.002 ()
To edit the IP Gateway Address for the Ethernet M&C port for this unit, use the
◄ ►arrow keys
to select a digit to edit, and then use the
▲▼ arrow keys to change that digit. Press ENTER
when done.
CONFIG: IP  Addresses  Address/Range
Ethernet IP Address/Range:
192.168.001.002/24 ()
To configure the IP Address for the Ethernet M&C port for this unit, use the
◄ ►arrow keys to
select a digit to edit, and then the
▲▼ arrow keys to change that digit. Press ENTER when done.
5.2.1.13.2 CONFIG: IP  SNMP
SNMP:
Communities Traps ()
Use the
◄ ►arrow keys to select Communities or Traps, and then press ENTER.
CONFIG: IP  SNMP  Communities
SNMP Communities:
Read Write ()
Use the
◄ ►arrow keys to select Read or Write, and then press ENTER.
CONFIG: IP  SNMP  Communities  Read
SNMP Read Community:
Public (20 chars) ()
