Comtech EF Data CDM-625 - 2.2 Installing Into a Rack Enclosure

CDM-625 Advanced Satellite Modem Revision 13
Installation MN-CDM625
2–2
2.2 Installing Into a Rack Enclosure
When mounting the CDM-625 into a rack enclosure (Figure 2-1):
•
PROPER GROUNDING PROTECTION IS REQUIRED. The equipment must be
connected to the protective earth connection at all times. It is therefore imperative
that the unit is properly grounded, using the ground stud provided on the unit rear
panel, during installation, configuration, and operation.
• In Finland: "Laite on liitettävä suojamaadoituskoskettimilla varustettuun
pistorasiaan."
• In Norway: “Apparatet må tilkoples jordet stikkontakt.”
• In Sweden: “Apparaten skall anslutas till jordat uttag.”
•
PROPER AIR VENTILATION IS REQUIRED. In a rack system where there is high
heat discharge, provide forced-air cooling with top- or bottom-mounted fans or
blowers.
o Make sure there is adequate clearance inside the enclosure, especially at
the side for air ventilation.
o Air temperature inside the rack enclosure should never exceed 50
°
C
(122
°
F).
For information about custom rack enclosures, contact Comtech EF Data
Customer Support during normal business hours or visit Comtech EF Data’s Web
site (
www.comtechefdata.com/support.asp).
As shown in Figure 2-1: Once opened, inspect the shipment:
Step
Task
1 Keep all shipping materials for storage or reshipment.
2 Check the packing list to ensure the shipment is complete.
3
Inspect the equipment for any possible damage incurred during shipment.
Contact the carrier and Comtech EF Data immediately and submit a damage report if
damage is evident to the shipment.
4
Review
the manual carefully to become familiar with operation.
5
Proceed to Sect. 2.2 Installing and Mounting the CDM-625
