CDM-625 Advanced Satellite Modem Revision 13

Appendix E MN-CDM625

E–69

E.3.9 Home > Logs Submenu

Open the Logs submenu from the Home menu. This submenu contains the following options:

Hot

Key

Dialog Window Sect.

A Base Modem E.3.9.1

Packet Processor

E.3.9.2

Press a hot key to access a submenu. See the specified appendix section for further information.

Otherwise, press [ESC] to return to the Home menu.
