1.3.10.2 Front Panel
Chapter 5. FRONT PAN EL OPERATION
The LEDs indicate, in a summary fashion, the status of the modem.
2 Keypad
The keypad comprises six individual keyswitches. The keys have a
positive ‘click’ action that provides tactile feedback. Enter data via
the k eypad. D ata, pr ompts, and m essages ar e di splayed on t he
5.1.2
3
Vacuum
Fluorescent
Display (VFD)
The VFD i s an active di splay s howing t wo l ines of 40 characters
each. It produces a blue light with adjustable brightness. Nested
menus display all available options and pr ompt you to carry out a
5.1.3
Figure 1-3. CDM-625 Front Panel Features
