CDM-625 Advanced Satellite Modem Revision 13
Front Panel Operation MN-CDM625
5–87
Depending on 70/140 MHz or L-Band operation: Use to monitor and control a standalone or
redundant Comtech EF Data RF Transceiver (CSAT-5060 or KST-2000A/B) or LPOD BUC if
connected.
5.2.8 SELECT: FAST Menus
The d isplay example a s s hown h ere d epicts a unit s hipped w ith th e T wo-
channel A udio D rop h ardware o ption i nstalled. I f th is h ardware i s not
included, ‘Audio’ does not appear on the bottom line.
FAST: Options Demo-Mode CnC
Baseboard S/N 123456789 HW Rev1.X Audio
FAST (Fully Accessible System Topology) allows you to enable new options in the modem. Use
the
◄ ►arrow keys to select Options, Demo-Mode, or CnC, and then press ENTER.
5.2.8.1 FAST: Options
FAST options: View Options
Set Registers ()
You can access the FAST options via three separate internal EEPROM registers. Each register
requires its own FAST access code. Use the
◄ ►arrow keys to select View Options or Set
Registers (to continue via the correct register menu), and then press ENTER.
5.2.8.1.1 FAST: Options View Options
FAST: View options: 01 ()
Base 5 Mbps data rate installed
Use the
▲▼ arrow keys to scroll through the available options. The modem identifies each
selected FAST option as “installed” or “not installed”.
You must contact a Comtech EF Data sales representative, during normal business hours or via
e-mail to
sales@comtechefdata.com, to purchase the FAST Access Code for the desired option.
Available options include:
► Data Rate
► Data Rate when configured for TPC/LDPC
► Data Rate when configured for CnC (DoubleTalk
Carrier-in-Carrier)
► Data Rate when configured for VersaFEC
