CDM-625 Advanced Satellite Modem Revision 13
Appendix F MN-CDM625
F–26
HPA: Comms:OK 9.75V:OK
Over-Temp:OK Bias:OK -5V:OK
Once any KST Alarms screen has been viewed, press ENTER or CLEAR to return to the previous
menu.
F.3.3.3.3.4 ODU: FSK-control  BUC
The menus that follow assume that you have selected and the system has identified a
BUC connected via the Tx IF port.
BUC controls via FSK:
Configuration Status Advanced-FSK ()
Use the
◄ ►arrow keys to select Configuration, Status, or Advanced-FSK, and then press ENTER.
F.3.3.3.3.4.1 ODU: FSK-control  BUC  Configuration
BUC: Tx:On (Off,On)
Addr:01 (1-15) ()
Use the
◄ ►arrow keys to select Tx: or Addr:
On the top line – For Tx: use the
▲▼ arrow keys to select Off or On.
On the bottom line – For Addr: use the
▲▼ arrow keys to select an address from 01 to 15.
Press ENTER when done.
F.3.3.3.3.4.2 ODU: FSK-control  BUC  Status
BUC: Pwr=16.2dBm=00.0W Pclass=5 W
PLL=locked +045°C Sw-Ver=01
This screen provides read-only status information for the BUC setup. Press ENTER or CLEAR to
return to the previous menu.
F.3.3.3.3.4.3 ODU: FSK-control  BUC  Advanced-FSK
Advanced FSK:
CEFD BUC Type: LPOD (LPOD,2LPODs) ()
Use the ▲▼arrow keys to select LPOD or 2LPODs, and then press ENTER.
