Comtech EF Data CDM-625 - 18.5 IP Packet Processor Field Upgrade Procedure

CDM-625 Advanced Satellite Modem Revision 13
IP Packet Processor Option MN-CDM625
18–9
18.5 IP Packet Processor Field Upgrade Procedure
18.5.1 Overview
This section describes the procedure required to field upgrade any user CDM-625-Advanced Satellite Modem having a 175W AC or 125W
DC Power Supply with the optional IP Packet Processor card. See Sections 18.1.1 and 18.1.2 in this chapter for a detailed description of
the requirements and limitations of using the IP Packet Processor with the CDM-625.
18.5.2 Requirements for Field Upgrade
• CDM-625 Advanced Satellite Modem with 175W AC or 125W DC Power Supply, and Firmware Version 1.5.0 or later
• Medium Phillips screwdriver
• Needle-nose pliers
• CEFD P/N KT-0000176 IP Packet Processor with Fan Upgrade Kit, containing:
CEFD Part Number
QTY
Description
PL-0000449
1
Fan Assembly, 40 x 40 x 10
FN/FGDC12V01
1
Fan Guard
HW/4-40X3/4PH
4
Screw, S.S., 4-40 x 3/4 LG, Pan Head Phillips
HW/440HXNUTLOC
4
Locking Hex Nut, S.S., 4-40
PL-0000481
1
CDM-625 IP Packet Processor Card
HW/SEM440X1/4PH
2
Screw, S.S., 4-40 x 1/4 LG, Pan Head Phillips
