CDM-625 Advanced Satellite Modem Revision 13
Preface MN-CDM625
xxix
ground, line and neutral conductors. The equipment is not designed for connection
to a power system that has no direct connection to ground.
imperative during installation, configuration, an
d operation for the user to ensure
that the unit has been properly grounded using the ground stud provided on the
rear panel of the unit.
• In Finland: "Laite on liitettävä suojamaadoituskoskettimilla varustettuun
pistorasiaan."
• In Norway: “Apparatet må tilkoples jordet stikkontakt.”
• In Sweden: “Apparaten skall anslutas till jordat uttag.”
Electrical Installation
The unit is rated for a nominal operating range of 100-240 volts AC; for the appropriately
equipped DC option, nominal operating range is 43-60 volts DC. The unit has a maximum power
consumption of 300 watts.
The installation and connection to the line supply must be made in compliance to local or
national wiring codes and regulations.
The CDM-625 is shipped with a line inlet cable suitable for use in the country of operation. If it is
necessary to replace this cable, ensure the replacement has an equivalent specification.
Examples of acceptable ratings for the cable include HAR, BASEC and HOXXX-X.
Examples of acceptable connector ratings include VDE, NF-USE, UL, CSA, OVE, CEBEC, NEMKO,
DEMKO, BS1636A, BSI, SETI, IMQ, KEMA-KEUR and SEV.
Battery
THE MODEM CONTAINS A LITHIUM BATTERY. DANGER OF EXPLOSION EXISTS IF THE
BATTERY IS INCORRECTLY REPLACED. REPLACE ONLY WITH THE SAME OR EQUIVALENT
TYPE RECOMMENDED BY THE MANUFACTURER. DISPOSE OF USED BATTER
IES IN
ACCORDANCE WITH LOCAL AND NATIONAL REGULATIONS.
Fuses
FOR CONTINUED OPERATOR SAFETY, ALWAYS REPLACE THE FUSES WITH THE CORRECT
TYPE AND RATING.
The CDM-625 is fitted with two fuses:
