CDM-625 Advanced Satellite Modem Revision 13
Appendix F MN-CDM625
F–20
After viewing any CSAT/CSAT#X Info screen, press ENTER or CLEAR to return to the previous
menu.
ODU: FSK-control  CSAT (2CSATs  CSAT #X)  Info  Model
Model: CSAT-5060/025 V2.19
S/N: 010300346
Use this screen to view the CSAT model number, its operating firmware, and the unit serial
number.
ODU: FSK-control  CSAT (2CSATs  CSAT #X)  Info  Tx
Info: Tx:Off 6427.0MHz 23.00dB
Amp:Off Unmuted Slope:0.3
Use this screen to view the Tx state, Frequency, Tx Attenuation, Amplifier state, Tx Mute state
and Tx Slope adjustment (value or CAL).
ODU: FSK-control  CSAT (2CSATs  CSAT #X)  Info  Rx
Info: Rx:ON 3400.0MHz 18.00dB
Ref:087 Unmuted Slope:0.2
Use this screen to view the Rx state, Rx Frequency, Rx Attenuation, Rx Reference, Rx Mute state
and Rx Slope adjustment (value or CAL).
ODU: FSK-control  CSAT (2CSATs  CSAT #X)  Info  Misc
Info: Cold-Start:Off
Auto-Fault-Recovery:Summary (EC)
Use this screen to view the Cold Start and Auto Fault Recovery settings.
ODU: FSK-control  CSAT (2CSATs  CSAT #X)  Info  LNA
Info: LNA:Off Fault-Logic:Summary
Window:48% (EC)
Use this screen to view the Low Noise Amplifier operational settings.
