CDM-625 Advanced Satellite Modem Revision 13
Front Panel Operation MN-CDM625
5–55
-and-
2. WAN Buffer Length must be large enough, so that
Data Rate in kbps x buffer
length / 4096 ≥ 24
.
The actual negotiated speed (NegoSpeed:) is provided here as a read-only status display.
On the bottom line – Use the
▲▼ arrow keys to edit the desired speed setting. Note the
following:
Selection Function
Auto
Sets the port speed as Auto Negotiated. This allows the ports to negotiate speed and half/duplex
operation.
100Full Forces the Port to 100/Full.
100Half Forces the Port to 100/Half.
10Full Forces the Port to 10/Full.
10Half Forces the port to 10/Half.
CONFIG: IP IP Setup DDMgmtPt (Dedicated Management Port)
Dedicated Management Port: Port1
(Disabled,Port1,Port2,Port3,Port4) ()
Dedicated Management Port mode is not available when the optional IP Packet
Processor card is installed and enabled
. Should you attempt to execute this
command under such a configuration, the screen is non-functional, and appears as
follows:
Dedicated Management Port: Disabled
(Fixed @ Disabled with PktP Present) (
Use Dedicated Management Port mode in redundancy applications. When a redundant
CDM-625 is Offline (Standby), all four of the offline modem’s Ethernet ports are disabled
unless
you configure one of the four ports as the ‘Dedicated Management Port.’
Use the
▲▼ arrow keys to set the ‘Dedicated Management Port’ as Disabled, or select one of
the Ethernet ports (Port1, Port2, Port3 or Port4). Press ENTER when done.
To Next Page
