CDM-625 Advanced Satellite Modem Revision 13
Front Panel Operation MN-CDM625
5–57
CONFIG: IP IP Setup VLAN PortMode
Port Mode:
Port1 Port2 Port3 Port4 ()
Use the
◄ ►arrow keys to select Port1, Port2, Port3 or Port4, and then press ENTER.
CONFIG: IP IP Setup VLAN PortMode Port#
Port #: Port Mode= Trunk
PVID=N/A ()
Where # denotes the selected Port, use the
◄ ►arrow keys to select the operation parameter.
Then, use the
▲▼ arrow keys to select Access or Trunk.
When Port Mode is selected as Trunk, VLAN ID (PVID) is not applicable. On the bottom line of
the display, the selected port’s PVID will display as
PVID=N/A.
Otherwise, when Port Mode set to Access, configure the VLAN IDs (PVIDs). To edit the PVID, first
use the
◄ ►arrow keys to select a digit to edit, and then use the ▲▼ arrow keys to change that
digit. Enter a PVID in the range from 0001 to 4095. The default is 0001.
Hold down the ▲ ▼ arrow keys to quickly scroll between 0001 and 4095.
CONFIG: IP IP Setup VLAN VLAN-Table
VLAN Table:
View/Edit/Delete Add-Entry ()
The VLAN table supports up to 32 entries. Use the
◄ ►arrow keys to select View/Edit/Delete
or Add-Entry, and then press ENTER
.
CONFIG: IP IP Setup VLAN VLAN-Table View / Edit / Delete
VLAN ID:0001 P1:Filtered P2:Untagged
P3:Tagged P4:Untagged ACT=None(N,E,D)
To view, edit, or delete existing VLAN IDs, first use the
◄ ►arrow keys to select the desired
parameter:
• VLAN ID – Selects the tabulated VLAN ID. After selecting VLAND ID, use the
▲▼ arrow
keys to scroll through the available VLAN IDs.
