CDM-625 Advanced Satellite Modem Revision 13
Front Panel Operation MN-CDM625
5–59
• Delete the selected VLAN ID. After targeting a VLAN ID for deletion, use the
◄ ►arrow
keys to select the ACT parameter, and then use the
▲▼ arrow keys to select ACT=Del.
Press ENTER to execute deletion of the selected VLAN ID.
You must take into consideration that, when deleting VLAN IDs, an entry
associated with an enabled
PVID cannot be deleted.
CONFIG: IP IP Setup VLAN VLAN-Table Add-Entry
VLAN ID:???? P1:Tagged P2:Tagged
P3:Tagged P4:Untagged ADD ()
To add new entries to the VLAN table:
• First, use the
◄ ►arrow keys to select the ???? character string following the VLAN ID:
parameter.
• Then, use the
▲▼ arrow keys to replace the string with a new VLAN ID.
Hold down the ▲▼ arrow keys to quickly scroll between 1 and 4095.
• Next, use the
◄ ►arrow keys to select the port (P1/Port1 through P4/Port4), and then
use the
▲▼ arrow keys to set the behavior attribute for that port as Tagged, Filtered,
or Untagged.
The port attribute assignment restrictions explained previously apply.
• Once you assign the VLAN ID and the port behavior attributes, press ENTER to create
the new entry. You are then returned to the previous menu.
Note the following:
• If you attempt to add an entry that is named identically to an existing VLAN ID, an error
message displays as follows:
•
ERROR: vid already exists in table
• If you attempt to add a new entry, and the VLAN table has already reached the 32
maximum allowable entries, an error message displays as follows:
Can not add new entry!
VLAN table is FULL!
