CDM-625 Advanced Satellite Modem Revision 13
Front Panel Operation MN-CDM625
5–63
IP Stats Type
(Use ▲▼ to select)
Available Statistics
(Use ◄ ► to navigate to the bottom line, and then ▲▼ to display a desired statistic)
• WAN
HDLC Frames In / Out
Tx Dropped
Rx CRC Error
•
Port 1
• Port 2
• Port 3
• Port 4
• HDLC FPGA
• Management
Unicasts 511 Octets
*Indicates In only
**Indicates Out only
Broadcasts 1023 Octets
Pause Max Octets
Multicasts Jabber*
FCS Error Oversize*
Align Error* Discards
Good Octets Filtered*
Bad Octets* Collisions**
Undersize Multiple**
Fragments* Single**
64 Octets Deferred**
127 Octets Late**
255 Octets Excessive**
To clear the IP Statistics accumulators, use the
◄ ►arrow keys to move the cursor to Clr:N;
then, use the
▲▼ arrow keys to select Clr:Y. Press ENTER when done.
CONFIG: IP  IP Setup  FrmSize
This feature is supported only on modems with Hardware Version 2.X or higher.
2048 Ethernet Frame Size:
Enabled (Dis/Ena) ()
Use the
▲▼ arrow keys to set 2048-byte Ethernet packet sizes as Enabled or Disabled, and then
press ENTER.
