CDM-625 Advanced Satellite Modem Revision 13

Ethernet-based Remote Product Management MN-CDM625

6–4

The CDM-625 supports the following Alarms and Faults SNMPv1 traps / SNMPv2 notifications:

Alarms and Faults SNMPv1 traps

cdm625UnitAlarmV1 6247641

cdm625TxTrafficAlarmV1 6247642

cdm625RxTrafficAlarmV1 6247643

cdm625OpenNetworkAlarmV1 6247644

cdm625BUCAlarmV1 6247645

cdm625LNBAlarmV1 6247646

cdm625RedundancyStateTrapV1 6247647

Alarms and Faults SNMPv2 notifications:

cdm625UnitAlarm 1.3.6.1.4.1.6247.34.2.0.1

cdm625TxTrafficAlarm 1.3.6.1.4.1.6247.34.2.0.2

cdm625RxTrafficAlarm 1.3.6.1.4.1.6247.34.2.0.3

cdm625OpenNetworkAlarm 1.3.6.1.4.1.6247.34.2.0.4

cdm625BUCAlarm 1.3.6.1.4.1.6247.34.2.0.5

cdm625LNBAlarm 1.3.6.1.4.1.6247.34.2.0.6

cdm625RedundancyStateTrap 1.3.6.1.4.1.6247.34.2.0.7
