CDM-625 Advanced Satellite Modem Revision 13
Ethernet-based Remote Product Management MN-CDM625
6–32
Enter t he des ired N ext H op I P Address f or toLAN routes. N ote t hat no N ext H op ent ry i s
needed for toWAN routes.
When the optional Header Compression FAST feature is available, use the drop-down list to
Disable or Enable operations.
When the optional Payload Compression FAST feature is available, use the drop-down list to
Disable or Enable operations.
When t he opt ional AES Encryption F AST f eature i s av ailable, use t he dr op-down lis t t o
Disable or Enable operations.
With AES Encryption disabled, all routed traffic is transmitted ‘in the
clear’ regardless of the Encryption Key specified in the Route Table.
Key
With enc ryption enabled, u se t he dr op-down l ist t o s elect Key 1 through Key 8 (assigned
using the ‘Configuration | WAN | Encryption’ page, Sect. 6.5.4.3.5.3) or Random Key.
You must program all eight encryption and decryption keys before
selecting Random Key – otherwise, the modem will select any of the eight
allotted keys, even if a key is currently clear (set to all zeroes).
Click [Submit Changes] to save these settings.
Add New Route
This section allows you to directly add a route entry using text boxes and drop-down lists as
described previously for the Route Table (Edit) section.
Click [Add Entry] to save these settings. Note that, when a new route is added, the index
automatically increments to the next available number.
Delete Route
Enter Route Index to Delete, and then click [Delete Entry] once all changes have been made in
this section. The specified route entry will then be deleted from the route table.
