CDM-625 Advanced Satellite Modem Revision 13
Ethernet-based Remote Product Management MN-CDM625
6–45
[ -0.000 / (Tx Data Rate)] The minimum bandwidth will be s erved first among the
Assured Forwarding (ASFD) classes in case of bandwidth availability once Class
Selector 7 through Class Selected 1 have been serviced.
ASFD Class 4 through 1 Code Points (b100xx0, b011xx0, b010xx0, and b001xx0)
carry the drop precedence value (xx). In case of network congestion, a W eighted
Random E arly Detection ( WRED) c ongestion av oidance algorithm i s imposed on
these queues to drop the packets randomly rather than ‘tail drop.’
• Low Drop Precedence (% full) [0–100] – In case of congestion, the WRED
is applied af ter the queue dept h ex ceeds the configured percentage v alue
assigned for the Drop Precedence value b001.
• Med. Drop Precedence (% full) [0–99] – In case of congestion, the WRED
is applied af ter the queue dept h ex ceeds the configured percentage v alue
assigned for the Drop Precedence value b010.
• High Drop Precedence (% full)) [0–99] – In case of congestion, the WRED
is applied af ter the queue dept h ex ceeds the configured percentage v alue
assigned for the Drop Precedence value b011.
Click [Submit] to save these settings.
