Chapter 5. FRONT PANEL OPERATION

Use this page to configure the following overhead interfaces:

• ESC including Tx / Rx IDR Esc Type, Audio Volume, High Rate ESC

• IDR Backward Alarms for Tx 1-4 and Rx 1-4

• AUPC (when Carrier-in-Carrier Automatic Power Control is disabled/de-activated)

• CnC-APC (when Carrier-in-Carrier Automatic Power Control is enabled/activated)

See Sect. 10.6 Carrier-in-Carrier Automatic Power Control (CnC-APC) in

Chapter 10. D

OUBLETALK CARRIER-IN-CARRIER OPTION

for complete details

about, and setup of, the CnC-APC feature.

• EDMAC Framing Mode and Slave Address

Click [Submit] to save these settings.
