CDM-625 Advanced Satellite Modem Revision 13
Ethernet-based Remote Product Management MN-CDM625
6–53
BERT Config
Use the drop-down lists provided in this section to configure Bit Error Rate Test for Tx or Rx as
On or Off; configure the pattern for Tx or Rx; and set Error Insertion as either Off or 10E-3.
Click [Submit BERT] once you select the desired BERT settings.
BERT Monitor
This read-only section displays the ongoing BERT. Click [Restart] to restart the BERT Monitor, or
[Update] to refresh a test already in progress.
Save / Load (Save takes precedence over Load)
The Save/Load feature stores and retrieves the CDM-625 Base Modem settings
only
. It does not include the optional IP Packet Processor settings.
As a safeguard, to prevent any inadvertent action the Save Location and Load Location drop-
down lists’ default selections are Don’t Save and Don’t Load, respectively. Otherwise:
• Save Location / Load Location – Use the drop-down lists to save or load up to 10 different
modem configurations – 0 through 9. An empty location is noted on its menu line as
Available.
Click [Submit Save/Load] to save these settings.
