CDM-625 Advanced Satellite Modem Revision 13
Appendix B MN-CDM625
B–3
(Co+No)
/No
Eb/No
Uncoded
BPSK
Eb/No
Rate 1/2
BPSK
Eb/No
Rate 21/44
BPSK
Eb/No
Rate 5/16
BPSK
Eb/No
Uncoded
QPSK
Eb/No
Rate 1/2
QPSK
Eb/No
Rate 3/4
QPSK
Eb/No
Rate 7/8
QPSK
Eb/No
Rate 0.95
QPSK
Eb/No
Rate 2/3
8-PSK
Eb/No
Rate 3/4
8-PSK
Eb/No
Rate 7/8
8-PSK
Eb/No
Rate 0.95
8-PSK
Eb/No
Rate 3/4
16-QAM
Eb/No
Rate 7/8
16-QAM
1.4
- - - 0.8 - - - - - - - - - - -
1.6
- - - 1.5 - - - - - - - - - - -
1.8
- - - 2.1 - - - - - - - - - - -
2.0
- 0.7 0.9 2.7 - - - - - - - - - - -
2.2
- 1.2 1.4 3.2 - - - - - - - - - -
2.4
- 1.7 1.9 3.7 - - - - - - - - - - -
2.6
- 2.1 2.3 4.2 - - - - - - - - - - -
2.8
- 2.6 2.8 4.6 - - - - - - - - - - -
3.0 0.0 3.0 3.2 5.0 - - - - - - - - - - -
3.5 0.9 3.9 4.1 5.9 - 0.9 - - - - - - - - -
4.0 1.8 4.8 5.0 6.8 - 1.8 - - - - - - - - -
4.5 2.6 5.6 5.8 7.6 - 2.6 0.8 - - - - - - - -
5.0 3.3 6.3 6.5 8.4 - 3.3 1.5 0.9 - - - - - - -
5.5 4.1 7.1 7.3 9.1 1.1 4.1 2.3 1.7 1.3 - - - - - -
6.0 4.7 7.7 7.9 9.8 1.7 4.7 2.9 2.3 1.9 - - - -
- -
6.5 5.4 8.4 8.6 10.4 2.4 5.4 3.6 3.0 2.6 - - - - - -
7.0 6.0 9.0 9.2 11.1 3.0 6.0 4.2 3.6 3.2 - - - - - -
7.5 6.6 9.6 9.8 11.7 3.6 6.6 4.8 4.2 3.8 - - - - - -
8.0 7.3 10.3 10.5 12.3 4.3 7.3 5.5 4.9 4.5 - - - - - -
8.5 7.8 10.8 11.0 12.9 4.8 7.8 6.0 5.4 5.0 4.8 - - - - -
9.0 8.4 11.4 11.6 13.4 5.4 8.4 6.6 6.0 5.6 5.4 4.9 - - - -
9.5 9.0 12.0 12.2 14.0 6.0 9.0 7.2 6.6 6.2 6.0 5.5 4.8 4.5 - -
10.0 9.5 12.5 12.7 14.6 6.5 9.5 7.7 7.1 6.7 6.5 6.0 5.3 5.0 - -
10.5 10.1 13.1 13.3 15.1 7.1 10.1 8.3 7.7 7.3 7.1 6.6 5.9 5.6 5.3 -
11.0 10.6 13.6 13.8 1
5.7 7.6 10.6 8.8 8.2 7.8 7.6 7.1 6.4 6.1 5.8 5.2
11.5 11.2 14.2 14.4 16.2 8.2 11.2 9.4 8.8 8.4 8.2 7.7 7.0 6.7 6.4 5.8
12.0 11.7 14.7 14.9 16.7 8.7 11.7 9.9 9.3 8.9 8.7 8.2 7.5 7.2 6.9 6.3
12.5 12.2 15.2 15.4 17.3 9.2 12.2 10.4 9.8 9.4 9.2 8.7 8.0 7.7 7.4 6.8
13.0 12.8 15.8 16.0 17.8 9.8 12.8 11.0 10.4 10.0 9.8 9.3 8.6 8.3 8.0 7.4
13.5 13.3 16.3 16.5 18.3 10.3 13.3 11.5 10.9 10.5 10.3 9.8 9.1 8.8 8.5 7.9
14.0 13.8 16.8 17.0 18.8 10.8 13.8 12.0 11.4 11.0 10.8 10.3 9.6 9.3 9.0 8.4
14.5 14.3 17.3 17.5 19.4 11.3
14.3 12.5 11.9 11.5 11.3 10.8 10.1 9.8 9.5 8.9
15.0 14.9 17.9 18.1 19.9 11.9 14.9 13.1 12.5 12.1 11.9 11.4 10.7 10.4 10.1 9.5
15.5 15.4 18.4 18.6 20.4 12.4 15.4 13.6 13.0 12.6 12.4 11.9 11.2 10.9 10.6 10.0
16.0 15.9 18.9 19.1 20.9 12.9 15.9 14.1 13.5 13.1 12.9 12.4 11.7 11.4 11.1 10.5
16.5 16.4 19.4 19.6 21.4 13.4 16.4 14.6 14.0 13.6 13.4 12.9 12.2 11.9 11.6 11.0
17.0 16.9 19.9 20.1 21.9 13.9 16.9 15.1 14.5 14.1 13.9 13.4 12.7 12.4 12.1 11.5
17.5 17.4 20.4 20.6 22.4 14.4 17.4 15.6 15.0 14.6 14.4
13.9 13.2 12.9 12.6 12.0
18.0 17.9 20.9 21.1 23.0 14.9 17.9 16.1 15.5 15.1 14.9 14.4 13.7 13.4 13.1 12.5
18.5 18.4 21.4 21.6 23.5 15.4 18.4 16.6 16.0 15.6 15.4 14.9 14.2 13.9 13.6 13.0
19.0 18.9 21.9 22.1 24.0 15.9 18.9 17.1 16.5 16.1 15.9 15.4 14.7 14.4 14.1 13.5
19.5 19.5 22.5 22.7 24.5 16.5 19.5 17.7 17.1 16.7 16.5 16.0 15.3 15.0 14.7 14.1
20.0 20.0 23.0 23.2 25.0 17.0 20.0 18.2 17.6 17.2 17.0 16.5 15.8 15.5 15.2 14.6
Not
es
: IBS Framing: add 0.2 dB EDMAC Framing: rates b
elow 2048 kbps add 0.2 dB, othe
rwise 0 Reed-Solomon: add an additional 0.4 dB to the values shown
